Product Information
The Aga Ellesmere EC5W Wide Multi Fuel / Wood Burning Stove is the widest of the Ellesmere range and makes a real statement whilst retaining the beautiful Ellesmere design. As well as keeping to the traditional AGA design the EC5W Wide is SIA Eco Design 2022 ready and DEFRA approved for use in smoke controlled areas for the burning of wood.
The Ellesmere EC5W Wide has a heat output range of 5Kw-9Kw which means this stove is great for medium to large sized rooms with a good efficiency of 79%, and a rating of A. As the Ellesmere EC5W has a good efficiency rating this means that you will get the maximum from your fuel, which will save you on running costs. In addition to this the large cast iron door and solid steel body will retain heat long after your fuel has burnt away.
The larger width makes the EC5W wide more suited to the largest of chimney breasts and fireplace openings and can be installed freestanding within an open plan living space. Measuring 57.5cm wide and 60.5cm high, this stove makes a real statement.
- DEFRA Approved
- Eco Design 2022 ready
- Heat output range of 5-9Kw
- Nominal heat output of 5Kw
- 79% efficiency rating
- Flue outlet 125mm (5”)
- Top or rear flue
Technical
Code | EC5W |
Heat Output | 5Kw |
Efficiency | 79% |
Energy Efficiency Class | A |
Width | 576mm |
Height | 628mm |
Depth | 375mm |
Weight | 117Kg |
Flue Diameter | 125mm (5") |
Flue Outlet | Top or Rear |
DEFRA Approved | Yes |
Eco Design Ready | Yes |
Cast Iron Or Steel | Steel |
Maximum Log Length | 330mm |
Suitable For 12mm Hearth | No |
Distance To Combustibles | |
Side | 550mm |
Rear | 350mm |
